Virtual Oscilloscope
Description
This virtual oscilloscope simulation is a powerful tool for students studying electricity, electrical and electronics engineering students, and teachers presenting circuit concepts. It realistically replicates the behavior of a dual-channel oscilloscope connected to AC (alternating current) and DC (direct current) sources, and lets users display two signals simultaneously or add them together in real time to explore signal superposition.
Components
The simulation includes:
- Two low-frequency function generators (LFG) with adjustable frequency, fine-tuning, amplitude, and offset, producing sine, triangular, and square waveforms
- Two DC sources
- Selectable channel modes: CH I, CH II, DUAL, and ADD (real-time sum of two signals)
- Real-time waveform display, replicating how signals appear on actual oscilloscope screens
- Screen magnifier for improved trace readability
Learning Outcomes
This hands-on tool provides a clear and visual introduction to waveforms, signal characteristics, signal superposition, and oscilloscope interpretation—ideal for physics and electronics instruction in a virtual lab setting. The ADD mode makes it especially useful for electrical and electronics engineering students exploring how signals combine.
Learn More
For more information about this simulation, see the Simulation Manual: Virtual Oscilloscope.
